• Compact and aerodynamic design minimizes air resistance in high speed vehicles.
• Transparent polycarbonate outer and inner lens provides clear signal light transmission.
• Strong mechanical strength, heat, and UV light resistance.
• Excellent protection from vibration, dust, moisture and high temperature.
• Available in customized color arrangements: Clear/Red/Blue/Amber/Green.
• Lead-free solder and electronic component used in accordance with European standards.
• LED Light Bars manufactured with EMC/EMI standards.
• Ready to be customized to meet your special requirements.
• Protection rating: IP65
|
Product Code
|
C – 14522 / CS
|
|
Operating Voltage
|
9 – 30 VDC
|
|
LED
|
3 WATT POWER LED
|
|
LED Life time
|
100.000 Hours
|
|
Flashing mode
|
7
|
|
Flashing sequence
|
2 – 4 Hz
|
|
Dimensions (mm)
|
1600×270×135 |
|
Mounting
|
Fixed
|
|
Cable
|
3.5 M Blue (Mode), Red (VDC), Black(GND)
|
|
Standards
|
ECE R65, ECE R10, SAE J
|
|
Quality system
|
CE, ISO 9001
|
