• Compact and aerodynamic design minimizes air resistance in high speed vehicles
• With rich module options including daytime running light, brake light, turn light, spotlight and traffic adviser, MVS Light enhances your ability to communicate with your surroundings
• Transparent polycarbonate outer and inner lens provides clear signal light transmission
• Ready to be customized to meet your special requirements
• Strong mechanical strength, heat, and UV light resistance
• Hard-coated lenses and durable housing minimize environmental damage
• Excellent protection from vibration, dust, moisture and high temperature.
• Available in customized color arrangements: Clear/Red/Blue/Amber/Green
• Lead-free solder and electronic component used in accordance with European standards
• Light Bars manufactured with EMC/EMI standards• Ready to be customized to meet your special requirements
• Protection rating: IP65
|
Product Code
|
E – 07822 / CM
|
|
Operating Voltage
|
9 – 30 VDC
|
|
LED
|
3 WATT POWER LED
|
|
LED Life time
|
100.000 Hours
|
|
Flashing mode
|
7
|
|
Flashing sequence
|
2 – 4 Hz
|
|
Dimensions (mm)
|
780×275×80
|
|
Mounting
|
Fixed
|
|
Cable
|
3.5 M Blue (Mode), Red (VDC), Black(GND)
|
|
Standards
|
ECE R65, ECE R10, SAE J
|
|
Quality system
|
CE, ISO 9001
|
